DS-K1T804MF-1
2 reviews
Discontinued
Fingerprint Access Control Terminal
IP Based Fingerprint Access Control Terminal
Fingerprint Recognition
TCP/IP and WiFi Connection
Mifare Card Reading
LCD Display Screen
Support Offline Operation
Max 3,000 card No
Max 100,000 Access Control Event
Max 3000 Figerprints Storage
Tampering and Duress Alarms
Connects to Third-Party Bell
| FRR (False Rejection Rate): | ≤0.01% |
| Fingerprint Capacity: | 3,000 Fingerprints; Up to 10 Fingerprints for Each Person |
| Card Reading Response Duration: | < 1 s |
| Card Reading Mode: | Supports Mifare Card, Including Cards with Special Shapes; Supports Reading Card in Metal Environment |
| Storage: | Up to 3,000 Valid Cards; |
| Up to 100,000 Event Records; | |
| Up to 150,000 Attendance Records | |
| Fingerprint Comparing Mode: | 1:1 and 1:N, N=3000 |
| Operation System: | Linux |
| FAR (False Accept Rate): | ≤0.001% |
| Card Reading Distance: | 0 to 4.5cm |
| Fingerprint Recognition Duration: | < 1 s |
| Fingerprint Recognizer: | Optical Fingerprint Recognizer Module |
| Device Interfaces | |
| Communication Interface: | TCP/IP, RS-485 (For Secure Door Control Unit) |
| External Card Reader: | Not Support |
| USB Interface: | USB2.0, Type A |
| Wi-Fi: | Not Support |
| Wiegand Interface: | Not Support |
| Output Interface: | Relay (Lock Output) × 1 |
| Input Interface: | Exit Button × 1, Door Sensor × 1 |
| Transmission Rate: | TCP/IP, RS-485: 19200 bps-N-8-1 |
| General | |
| LCD Screen: | 2.4-inch (320×240 LCD-TFT Display Screen) |
| Audio: | 1 Buzzer and 1 Loudspeaker |
| Appearance Color: | Black (Included), Gold (Optional), Silver (Optional), White (Optional) |
| Keyboard: | Keyboard (Without Back Light) |
| Power Supply: | 12 VDC/2 A |
| LED Indicator: | Power/Status (Red/Green) |
| Reset Key: | × 1 |
| Temper-Proof: | Support |
| Water-Proof: | IP42 |
| Installation: | Surface Mounting, Metal Door Mounting, Installation with Gang Box |
| Working Humidity: | 10% to 90% (Non-Condensing) |
| Working Temperature : | -10° C to 55° C (14° F to 131° F) |
| Dimensions (L×W×H): | 205 mm × 76.5 mm × 37 mm (8.07" × 3.01" × 1.46") |
